Emplacement #2
Battery Const. #293,
Fort McGilvray, HD Seward
Home  |  Seward  |  Btry #293 main

In addition to the gun positions themselves, both emplacements contain a powder room, one large shell room and two smaller shell rooms, an air compressor room and a small store room. Each of the small shell rooms housed 100 rounds of high explosive ammunition while the large shell room provided storage space for 400 armor piercing rounds.

Interestingly, at both Battery Const. #293 and Battery Const. #294 on Rugged Island, a small concrete shelter has been substituted for the typical 'Signal Corps Slab' near each of the gun positions.




Gun Position


The #2 gun position, looking northwest.
July 2004
The 'Signal Corps Shelter' looking south.
July 2004
The east entrance to the battery.
July 2004
Inside the 'Signal Corps Shelter'.
July 2004



Store Room and Air Compressor Room


Looking northeast into the air compressor room.
July 2004
Inside the store room.
July 2004
The northeast corner of the air compressor room.
July 2004
Looking southwest in the air compressor room.
July 2004
Looking southwest in the front corridor, past the store room door.
July 2005
Looking south in the store room.
July 2004
The air compressor room, looking southeast.
July 2004



Shell Rooms


Looking east in the front corridor, shell room doors to the left.
July 2004
Looking into the west high explosive shell room.
July 2004
Looking south down the entry corridor to the large shell room.
July 2004
Looking southeast in the large shell room.
July 2004
Looking into the east high explosive shell room.
July 2004
Looking southwest in the large shell room.
July 2004



Powder Room


The powder room doors, looking northwest.
July 2004
In the powder room, looking southeast.
July 2004
Looking northwest in the powder room.
July 2004
Looking southwest in the powder room.
July 2004
The northeast corner of the powder room.
July 2004
